Risers Cnc Tombstones

At Hidrofix, we manufacture CNC horizontal machining towers in the desired sizes and dimensions for every model of every brand of machining center. For custom CNC horizontal machining tower manufacturing, please contact us at our contact addresses.

Risers Cnc Tombstones

Risers are engineered to elevate the workpiece above the machine table, enabling efficient four-sided machining operations. Each riser is custom-designed to meet the specific requirements of your application, ensuring optimal setup and performance. They are particularly effective for accommodating spindle clearance constraints. When a smooth, featureless console surface is not preferred, our cube tombstones can be equipped with versatile grid systems, including the industry-standard 2″ grid, T-slots, or fully customized configurations.

Key Features

Compatible with both 1/2″ and 5/8″ systems, offering grid holes, precision bushings, and threaded inserts for flexible workholding
Hardened threaded inserts provide secure clamping at every hole location and can be easily replaced when worn, minimizing downtime
High-precision, heat-treated bushings are precisely positioned to ensure accurate, repeatable part alignment and excellent resistance to wear
Replacement bushings, inserts, and a dedicated extraction tool are available upon request to support long-term maintenance and reliability

Tolerance	Precision
Flatness (tombstones & plates)	0.0005 / 12×12
Parallelism (plates)	0.0005 / 12, Max 0.002 total
Perpendicularity	0.0008 / 12, Min 0.001, Max 0.002 / 48
Surface Finish	63 RMS
Face Thickness	≤18” = ±0.002, >18” = ±0.003
Tapped Holes (non-accumulative)	±0.005
Precision Bushing I.D.	+0.0013 / +0.0007
Precision Bushing Concentricity	0.0001
Bored or Precision Bushing Hole to Adjacent Hole	±0.0005
First Row Bushing Hole Location from Datums	±0.002
Bored or Precision Bushing Hole Spacing (non-accumulative)	0–10″: ±0.0005 10–20″: ±0.0008 20–30″: ±0.0010 30–40″: ±0.0012
Note:	For aluminum, increase these tolerances by 50%
